LVA95 Log Splitter Valve
Short Description:
LVA95 Log Splitter Machine Valve is through the lever action make valve core do axial movement and the oil circuit to switch straight acting reversing valve. The splitting machine valve owns overload protection, compact structure, flexible control, easy to use and reliable, dedicated to splitting machine oil circuit control, can make the splitting machine fast and stable work. Parameters (MPa) Nom. Pressure (MPa) Max. Pressure (L/ min) Nom. Flow rate (L/min) Max. Flow rate (MP...
Product Detail
Product Tags
LVA95 Log Splitter Machine Valve is through the lever action make valve core do axial movement and the oil
circuit to switch straight acting reversing valve. The splitting machine valve owns overload protection, compact
structure, flexible control, easy to use and reliable, dedicated to splitting machine oil circuit control, can make
the splitting machine fast and stable work.
Parameters
|
(MPa) Nom. Pressure |
(MPa) Max. Pressure |
(L/ min) Nom. Flow rate |
(L/min) Max. Flow rate |
(MPa) Back Pressure |
hydraulic oil | ||
|
(°c) Tem.rang |
(mm2/S ) Visc.rang |
（5m) filtrating accuracy |
|||||
|
20 |
25 |
95 |
95 |
W1 |
-20〜+80 |
10-400 |
W10 |
