DF350-3OT
Short Description:
DF350 directional control valve is specially designed for agricultural machines, with the features of low pressure-lose, high reliability easy to installand maintain. ♦ Single/double acting switch in each work section, available to connect single or double acting cylinder. ♦Single direction valve in each work section. ♦Multiple spool type for cylinder. motor. etc ♦ Structure:DF350:monoblock: l-5 sections. Parameters (MPa) Nom. Pressure (MPa) Max. Pressure (L/ min) Nom. Flow rate ...
Product Detail
Product Tags
DF350 directional control valve is specially designed for agricultural machines, with the features of low pressure-lose,
high reliability easy to installand maintain.
♦ Single/double acting switch in each work section, available to connect single or double acting cylinder.
♦Single direction valve in each work section.
♦Multiple spool type for cylinder. motor. etc
♦ Structure:DF350:monoblock: l-5 sections.
Parameters
|
(MPa) Nom. Pressure |
(MPa) Max. Pressure |
(L/ min) Nom. Flow rate |
(L/min) Max. Flow rate |
(MPa) Back Pressure |
hydraulic oil | ||
|
(°c) Tem.rang |
(mm2/S ) Visc.rang |
（5m) filtrating accuracy |
|||||
|
16 |
31.5 |
50 |
50 |
W1 |
-20〜+80 |
10-400 |
W10 |
